NETGEAR XS708T User Manual

Configure Switching
119
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
14. From the Flow Control menu, select one of the following options:
• Disable. The switch cannot receive pause frames for the port nor does it send pause
frames if incoming traffic on the port is congested (that is, the port buffers are full).
This the default setting.
• Symmetric. The switch can send and receive pause frames for the port. If incoming
traffic on the port is congested, the switch generates pause frames and sends them to
the peer. The switch can also adjust the transmission rate on the port in response to
incoming pause frames.
• Asymmetric. The switch can receive pause frames for the port but does not send
pause frames if incoming traffic on the port is congested. The switch can adjust the
transmission rate on the port in response to incoming pause frames.
15. Click the Apply button.
The updated configuration is sent to the switch. Configuration changes take effect
immediately.
The following table describes the nonconfigurable data that is displayed.
Configure Link Aggregation Groups
Link aggregation groups (LAGs), which are also known as port channels, allow you to
combine multiple full-duplex Ethernet links into a single logical link. Network devices treat the
aggregation as if it were a single link, which increases fault tolerance and provides load
sharing. You assign the LAG VLAN membership after you create a LAG. The LAG by default
becomes a member of the default management VLAN (that is, VLAN 1).
Table 28. Port Configuration information
Field Description
Port Type For normal ports this field is blank. Otherwise, the possible values are
as follows:
• Mirrored. The port is a mirrored port on which all the traffic is
copied to the probe port.
• Probe. Use this port to monitor a mirrored port.
• Trunk Member. The port is a member of a link aggregation trunk.
Look at the LAG pages for more information.
Physical Status Indicates the port speed and duplex mode.
Link Status Indicates whether the link is up or down.
MAC Address Displays the physical address of the specified interface.
PortList Bit Offset Displays the bit offset value that corresponds to the port when the MIB
object type PortList is used to manage in SNMP.
ifIndex The ifIndex of the interface table entry associated with this port.

NETGEAR XS708T Specifications

General

Switch type	Managed
Switch layer	L2+/L3
Quality of Service (QoS) support	Yes
USB 2.0 ports quantity	1
SFP+ module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity	8
Certification	CE, FCC Cl. A, VCCI Cl. A, Cl. A EN 55022 (CISPR 22), Cl. A C-Tick, EN 55024, CCC
Product color	Black
LED indicators	Activity, Link, Power
Number of fans	1 fan(s)
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN
Cable types supported	Cat5e, Cat6, Cat6a, Cat7
Copper ethernet cabling technology	10GBASE-T
Noise level	29.1 dB
Flash memory	256 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276832 h
Jumbo frames	9000
Latency (10 Gbps)	3.012 µs
MAC address table	16000 entries
Packet buffer memory	2 MB
Number of static routes	32
DHCP features	DHCP server, DHCP client
Security algorithms	802.1x RADIUS
Access Control List (ACL) rules	100
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	96 W
Operating altitude	0 - 3000 m
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2980 g
