Configure Switching
168
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
The System Information page displays.
5. Select Switching> Multicast > IGMP Snooping > Configuration.
The previous figure does not show the VLAN IDs Enabled For IGMP Snooping section
and the VLAN IDs Enabled For IGMP Snooping Querier section.
6. Select the IGMP Snooping Status Enable or Disable radio button.
This specifies the administrative mode for IGMP snooping for the switch. The default is
Disable.
7. Select the Validate IGMP IP header Enable or Disable radio button.
When IGMP IP header validation is enabled, any IGMP IP header must include the
Router Alert, ToS, and TTL information. Otherwise, the IGMP packet is discarded. The
default value is Enable.
8. Click the Apply button.
The updated configuration is sent to the switch. Configuration changes take effect
immediately.
9. To refresh the page with the latest information about the switch, click the Update button.
The following table displays information about the global IGMP snooping status and statistics
on the page.
Table 45. IGMP Snooping Configuration information
Field Description
Multicast Control Frame Count The number of multicast control frames that are processed by the CPU.
Interfaces Enabled for IGMP
Snooping
A list of all the interfaces currently enabled for IGMP snooping.
VLAN IDs Enabled For IGMP
Snooping
Displays VLAN IDs enabled for IGMP snooping.
VLAN IDs Enabled For IGMP
Snooping Querier
Displays VLAN IDs enabled for IGMP snooping querier.
