Configure Routing
212
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
Received Datagrams Discarded
Due To No Route
The number of input datagrams discarded because no route could be
found to transmit them to their destination.
Received Datagrams With Unknown
Protocol
The number of locally addressed datagrams received successfully but
discarded because of an unknown or unsupported protocol. This counter
is incremented at the interface to which these datagrams were addressed,
which might not be the input interface for some of the datagrams.
Received Datagrams Discarded
Due To Invalid Address
The number of input datagrams discarded because the IPv6 address in
their IPv6 header's destination field was not a valid address to be received
at this entity. This count includes invalid addresses (for example, ::0) and
unsupported addresses (such as addresses with unallocated prefixes).
For entities that are not IPv6 routers and therefore do not forward
datagrams, this counter includes datagrams discarded because the
destination address was not a local address.
Received Datagrams Discarded Dut
To Truncated Data
The number of input datagrams discarded because datagram frame didn't
carry enough data.
Received Datagrams Discarded
Other
The number of input IPv6 datagrams for which no problems were
encountered to prevent their continued processing, but that were
discarded for reasons such as lack of buffer space. This counter does not
include any datagrams discarded while awaiting reassembly.
Received Datagrams Reassembly
Required
The number of IPv6 fragments received that needed to be reassembled at
this interface. This counter is incremented at the interface to which these
fragments were addressed, which might not be the input interface for
some of the fragments.
Datagrams Successfully
Reassembled
The number of IPv6 datagrams successfully reassembled. This counter is
incremented at the interface to which these datagrams were addressed,
which might not be necessarily the input interface for some of the
fragments.
Datagrams Failed To Reassemble The number of failures detected by the IPv6 reassembly algorithm (for
whatever reason: timed out, errors, and so on). This is not necessarily a
count of discarded IPv6 fragments since some algorithms (notably the
algorithm in RFC 815) can lose track of the number of fragments by
combining them as they are received. This counter is incremented at the
interface to which these fragments were addressed, which might not be
the input interface for some of the fragments.
Datagrams Forwarded The number of output datagrams that this entity received and forwarded to
their final destinations. In entities that do not act as IPv6 routers, this
counter includes only those packets that were source-routed through this
entity, and the source-route processing was successful. For a successfully
forwarded datagram the counter of the outgoing interface is incremented.
Datagrams Locally Transmitted The number of datagrams that this entity successfully transmitted from this
output interface.
Datagrams Transmit Failed The number of datagrams that this entity failed to transmit successfully.
Table 58. IPv6 Statistics information (continued)
Field Description

NETGEAR XS708T Specifications

General

Switch type	Managed
Switch layer	L2+/L3
Quality of Service (QoS) support	Yes
USB 2.0 ports quantity	1
SFP+ module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity	8
Certification	CE, FCC Cl. A, VCCI Cl. A, Cl. A EN 55022 (CISPR 22), Cl. A C-Tick, EN 55024, CCC
Product color	Black
LED indicators	Activity, Link, Power
Number of fans	1 fan(s)
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN
Cable types supported	Cat5e, Cat6, Cat6a, Cat7
Copper ethernet cabling technology	10GBASE-T
Noise level	29.1 dB
Flash memory	256 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276832 h
Jumbo frames	9000
Latency (10 Gbps)	3.012 µs
MAC address table	16000 entries
Packet buffer memory	2 MB
Number of static routes	32
DHCP features	DHCP server, DHCP client
Security algorithms	802.1x RADIUS
Access Control List (ACL) rules	100
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	96 W
Operating altitude	0 - 3000 m
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2980 g
