Configure Routing
228
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
6. Navigate through the table by doing the following:
• From the Rows per page menu, select how many table entries are displayed per
page.
Possible values are 20, 50, 100, 200, and All. If you select All, the browser might be
slow to display the information.
• Click the < button to display the previous page of the table data entries.
• Click the > button to display the next page of the table data entries.
7. To refresh the page with the latest information about the switch, click the Update button.
The following table describes the nonconfigurable information displayed on the page.
Table 64. ARP cache information
Field Description
Management VLAN ARP Cache
IP Address The IP address associated with the system’s MAC address. This must be the IP
address of a device on a subnet attached to one of the switch’s existing routing
interfaces.
Port The associated interface ID of the connection.
MAC Address The unicast MAC address of the device. The address is six two-digit hexadecimal
numbers separated by colons, for example, 00:06:29:32:81:40.
Routing VLANs ARP Cache
IP Address The IP address. It must be the IP address of a device on a subnet attached to one of
the switch’s existing routing interfaces.
Interface The routing interface associated with the ARP entry.
MAC Address The unicast MAC address of the device. The address is six two-digit hexadecimal
numbers separated by colons, for example 00:06:29:32:81:40.
