NETGEAR XS708T User Manual

Monitor the System
359
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
Broadcast Packets Received The total number of packets received that were directed to the broadcast
address. This does not include multicast packets.
Receive Packets Discarded The number of inbound packets that were chosen to be discarded, even though
no errors were detected, in order to prevent their being delivered to a
higher-layer protocol. A possible reason for discarding a packet could be to free
up buffer space.
Octets Transmitted The total number of octets transmitted out of the interface, including framing
characters.
Packets Transmitted Without
Errors
The total number of packets transmitted out of the interface.
Unicast Packets Transmitted The total number of packets that higher-level protocols requested be transmitted
to a subnetwork-unicast address, including those that were discarded or not
sent.
Multicast Packets
Transmitted
The total number of packets that higher-level protocols requested be transmitted
to a multicast address, including those that were discarded or not sent.
Broadcast Packets
Transmitted
The total number of packets that higher-level protocols requested be transmitted
to the broadcast address, including those that were discarded or not sent.
Transmit Packets Discarded The number of outbound packets that were chosen to be discarded, even
though no errors were detected, in order to prevent their being delivered to a
higher-layer protocol. A possible reason for discarding a packet could be to free
up buffer space.
Most Address Entries Ever
Used
The highest number of Forwarding Database Address Table entries that were
learned by this switch since the most recent reboot.
Address Entries in Use The number of learned and static entries in the Forwarding Database Address
Table for this switch.
Maximum VLAN Entries The maximum number of VLANs allowed on this switch.
Most VLAN Entries Ever
Used
The largest number of VLANs that were active on this switch since the last
reboot.
Static VLAN Entries The number of active VLAN entries on this switch that were created statically.
VLAN Deletes The number of VLANs on this switch that were created and then deleted since
the last reboot.
Time Since Counters Last
Cleared
The elapsed time, in days, hours, minutes, and seconds, since the statistics for
this switch were last cleared.
Table 87. Switch statistics (continued)
Field Description

NETGEAR XS708T Specifications

General

Switch type	Managed
Switch layer	L2+/L3
Quality of Service (QoS) support	Yes
USB 2.0 ports quantity	1
SFP+ module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity	8
Certification	CE, FCC Cl. A, VCCI Cl. A, Cl. A EN 55022 (CISPR 22), Cl. A C-Tick, EN 55024, CCC
Product color	Black
LED indicators	Activity, Link, Power
Number of fans	1 fan(s)
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN
Cable types supported	Cat5e, Cat6, Cat6a, Cat7
Copper ethernet cabling technology	10GBASE-T
Noise level	29.1 dB
Flash memory	256 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276832 h
Jumbo frames	9000
Latency (10 Gbps)	3.012 µs
MAC address table	16000 entries
Packet buffer memory	2 MB
Number of static routes	32
DHCP features	DHCP server, DHCP client
Security algorithms	802.1x RADIUS
Access Control List (ACL) rules	100
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	96 W
Operating altitude	0 - 3000 m
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2980 g
