Configure System Information
69
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
The following table describes the nonconfigurable fields.
Table 20. Green Ethernet Local Device Information
Field Description
Cumulative Energy Saved on this
port due to Green mode(s) (Watts
* Hours)
Cumulative energy saved due to all green modes enabled on this port
in watts * hours.
Rx Low Power Idle Event Count This field is incremented each time MAC RX enters low-power idle
(LPI) state. Shows the total number of Rx LPI events since EEE
counters were last cleared.
Rx Low Power Idle Duration
(uSec)
This field indicates duration of Rx LPI state in 10 us increments. Shows
the total duration of Rx LPI since the EEE counters were last cleared.
Tx Low Power Idle Event Count This field is incremented each time MAC TX enters LPI state. Shows
the total number of Tx LPI events since EEE counters were last
cleared.
Tx Low Power Idle Duration
(uSec)
This field indicates duration of Tx LPI state in 10 us increments. Shows
the total duration of Tx LPI since the EEE counters were last cleared.
Tw_sys_tx (uSec) Integer that indicates the value of Tw_sys that the local system can
support.
Tw_sys_tx Echo (uSec) Integer that indicates the remote system’s Transmit Tw_sys that was
used by the local system to compute the Tw_sys that it wants to
request from the remote system.
Tw_sys_rx (uSec) Integer that indicates the value of Tw_sys that the local system
requests from the remote system.
Tw_sys_rx Echo (uSec) Integer that indicates the remote system’s Receive Tw_sys that was
used by the local system to compute the Tw_sys that it can support.
Fallback Tw_sys (uSec) Integer that indicates the value of fallback Tw_sys that the local system
requests from the remote system.
Tx_dll_enabled Data Link Layer Enabled: Initialization status of the EEE transmit Data
Link Layer management function on the local system.
Tx_dll_ready Data Link Layer ready: This variable indicates that the tx system
initialization is complete and is ready to update/receive LLDPDU
containing EEE TLV.
Rx_dll_enabled Status of the EEE capability negotiation on the local system.
Rx_dll_ready Data Link Layer ready: This variable indicates that the rx system
initialization is complete and is ready to update/receive LLDPDU
containing EEE TLV.
Time Since Counters Last Cleared Time Since Counters Last Cleared (since the time of power-up, or after
EEE counters are cleared).

NETGEAR XS708T Specifications

General

Switch type	Managed
Switch layer	L2+/L3
Quality of Service (QoS) support	Yes
USB 2.0 ports quantity	1
SFP+ module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity	8
Certification	CE, FCC Cl. A, VCCI Cl. A, Cl. A EN 55022 (CISPR 22), Cl. A C-Tick, EN 55024, CCC
Product color	Black
LED indicators	Activity, Link, Power
Number of fans	1 fan(s)
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN
Cable types supported	Cat5e, Cat6, Cat6a, Cat7
Copper ethernet cabling technology	10GBASE-T
Noise level	29.1 dB
Flash memory	256 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276832 h
Jumbo frames	9000
Latency (10 Gbps)	3.012 µs
MAC address table	16000 entries
Packet buffer memory	2 MB
Number of static routes	32
DHCP features	DHCP server, DHCP client
Security algorithms	802.1x RADIUS
Access Control List (ACL) rules	100
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	96 W
Operating altitude	0 - 3000 m
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2980 g
