NETGEAR XS708T User Manual

Configure System Information
72
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
The following table describes the nonconfigurable fields.
Configure the Green Ethernet EEE LPI History
Use this page to configure and view the Green Ethernet low power idle (LPI) history.
 To configure the port Green Ethernet EEE LPI history:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
Table 22. Green Ethernet Statistics Summary information
Field Description
Current Power Consumption by all
ports in Chassis (mWatts)
Estimated Power Consumption by all ports in chassis in mWatts.
Estimated Percentage Power
Saving per chassis (%)
Estimated percentage of power saved on all ports in chassis when
green modes are enabled.
Cumulative Energy Saving per
Chassis (Watts * Hours)
Estimated cumulative energy saved per chassis in watts * hour when all
green modes are enabled.
Unit The unit ID.
Green Features supported on this
unit
List of green features supported on the given unit, which could be one
or more of the following: Energy-Detect (Energy Detect), Short-Reach
(Short Reach), EEE (Energy Efficient Ethernet), LPI-History (EEE Low
Power Idle History), LLDP-Cap-Exchg (EEE LLDP Capability
Exchange), Pwr-Usg-Est (Power Usage Estimates).
Interface Interface for which data is displayed or configured.
Energy Detect Admin mode Enable or disable Energy Detect mode on the port. When this mode is
enabled, when the port link is down, the PHY automatically goes down
for a short period of time, then wakes up to check link pulses. This
allows the switch to perform autonegotiation and save power
consumption when no link partner is present.
Energy Detect Operational Status Current operational status of the Energy Detect mode.
Short Reach Admin mode Enable or disable Short Reach Admin mode on the port. With Short
Reach mode enabled, PHY is forced to operate in low power mode
irrespective of the cable length.
Short Reach Operational Status Current operational status of the Short Reach mode.
EEE Admin mode Enable or disable Energy Efficient Ethernet mode on the port. With
EEE mode enabled, the port transitions to low power mode during link
idle conditions.

NETGEAR XS708T Specifications

General

Switch type	Managed
Switch layer	L2+/L3
Quality of Service (QoS) support	Yes
USB 2.0 ports quantity	1
SFP+ module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity	8
Certification	CE, FCC Cl. A, VCCI Cl. A, Cl. A EN 55022 (CISPR 22), Cl. A C-Tick, EN 55024, CCC
Product color	Black
LED indicators	Activity, Link, Power
Number of fans	1 fan(s)
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN
Cable types supported	Cat5e, Cat6, Cat6a, Cat7
Copper ethernet cabling technology	10GBASE-T
Noise level	29.1 dB
Flash memory	256 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276832 h
Jumbo frames	9000
Latency (10 Gbps)	3.012 µs
MAC address table	16000 entries
Packet buffer memory	2 MB
Number of static routes	32
DHCP features	DHCP server, DHCP client
Security algorithms	802.1x RADIUS
Access Control List (ACL) rules	100
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	96 W
Operating altitude	0 - 3000 m
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2980 g
