Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 151
Up to 24 MPR-e radios can independently upload their RSL history file every 15
minutes when the rsl-history command is configured on the 7705 SAR for each
radio. When uploaded, the file is stored on the 7705 SAR compact flash. Each RSL
file can be up to 1 Mbyte and contain up to 10 000 lines. Each time a new file from a
specific MPR-e radio is sent to the 7705 SAR, the new file overwrites the previous
version for that radio. Once uploaded to the 7705 SAR, the operator can view the file
in its raw format using the file>type command or FTP it to an external server.
Table 19 lists the attributes in the RSL history file.
Table 19 RSL History Attributes
Attribute Description
Time Time of record
LocTxPower Local transmit power
RemTxPower Remote transmit power
LocRxPower Local received power
RemRxPower Remote received power
LocDivRxPower Local diversity received power (significant for diversity
configuration only)
RemDivRxPower Remote diversity received power (significant for diversity
configuration only)
LocXPD Local cross-polar discrimination (significant for XPIC
configuration only)
RemXPD Remote cross-polar discrimination (significant for XPIC
configuration only)
LocMSE Local mean squared error
RemMSE Remote mean squared error
TxMod Transmitter modulation
RxMod Receiver modulation
LocEPS Local equipment protection switching
RemEPS Remote equipment protection switching
LocRPS Local radio protection switching
RemRPS Remote radio protection switching
LocTPS Local transmit protection switching
