Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 575
Output Example (security firewall)
The following example shows an MDA fabric statistics display when the security firewall
keywords are used. The security firewall keywords apply only to the 7705 SAR-18 and
7705 SAR-8 (with CSMv2). Refer to the “Security Parameters” section in the
7705 SAR Router Configuration Guide for more information on firewall security.
*A:ALU-1# show mda 1/6 statistics security firewall
===============================================================================
Firewall Statistics
===============================================================================
-------------------------------------------------------------------------------
Firewall Queue Statistics
-------------------------------------------------------------------------------
Network Queue 1 Best-effort Packets Bytes
In Profile forwarded : 0 0
In Profile dropped : 0 0
Out Profile forwarded : 0 0
Out Profile dropped : 0 0
Network Queue 2 Expedited Packets Bytes
In Profile forwarded : 0 0
In Profile dropped : 0 0
Out Profile forwarded : 0 0
Out Profile dropped : 0 0
Access Queue 1 Best-effort Packets Bytes
In Profile forwarded : 0 0
In Profile dropped : 0 0
Out Profile forwarded : 0 0
Out Profile dropped : 0 0
Access Queue 2 Expedited Packets Bytes
In Profile forwarded : 0 0
In Profile dropped : 0 0
Out Profile forwarded : 0 0
Out Profile dropped : 0 0
===============================================================================
Encryption Queue CTL
Forwarded The number of packets and octets forwarded by the encryption
queue for control path traffic
Dropped The number of packets and octets dropped by the encryption
queue for control path traffic
Table 42 Show MDA Fabric Security Firewall Statistics Output Fields
Label Description
Network Queue 1 Best-
effort
The statistics for the best-effort network queue; queue 1 is
always for best-effort traffic
Table 41 Show MDA Fabric Security Encryption Statistics Output Fields
Label Description
