7705 SAR Interfaces
576
Interface Configuration Guide
3HE 11011 AAAC TQZZA Edition: 01
Output Example
The following example shows an MDA fabric statistics display if the with-fabric-stats
keyword is used.
*A:ALU-1# show mda with-fabric-stats
===============================================================================
Summary of MDA's With Fabric Stats Enabled
===============================================================================
Slot Mda Provisioned Type Admin Operational
Equipped Type (if different) State State
-------------------------------------------------------------------------------
1 1 a12-sdiv2 down provisioned
===============================================================================
*A:ALU-1>#
Network Queue 2
Expedited
The statistics for the expedited network queue; queue 2 is
always for expedited traffic
Access Queue 1 Best-
effort
The statistics for the best-effort access queue; queue 1 is
always for best-effort traffic
Access Queue 2 Best-
effort
The statistics for the expedited access queue; queue 2 is
always for expedited traffic
In Profile forwarded The number of packets and bytes forwarded by the security
queue for in-profile best-effort or expedited traffic
In Profile dropped The number of packets and bytes dropped by the security
queue for in-profile best-effort or expedited traffic
Out Profile forwarded The number of packets and bytes forwarded by the security
queue for out-of-profile best-effort or expedited traffic
Out Profile dropped The number of packets and bytes dropped by the security
queue for out-of-profile best-effort or expedited traffic
Table 43 Show MDA With Fabric Statistics Output Fields
Label Description
Slot The card slot number (always 1)
Mda The adapter card slot number
Provisioned Type The provisioned adapter card type
Equipped Type (if different) The adapter card type actually installed in the slot if
different from the provisioned type
Table 42 Show MDA Fabric Security Firewall Statistics Output Fields
Label Description
