7705 SAR Interfaces
596
Interface Configuration Guide
3HE 11011 AAAC TQZZA Edition: 01
Output Example
*A:ALU-1># show external-alarms output
=================================================================
Output Relay Summary
=================================================================
Output Id Name Type Admin State
-----------------------------------------------------------------
relay-1/1.d-1 output1 digital-out down off
relay-1/1.d-2 output2 digital-out down off
relay-1/1.d-3 output3 digital-out down off
relay-1/1.d-4 output4 digital-out down off
relay-1/1.d-5 output5 digital-out down off
relay-1/1.d-6 digital-out down off
relay-1/1.d-7 digital-out down off
relay-1/1.d-8 digital-out down off
=================================================================
*A:ALU-1>#
Table 49 Show External Alarm Output Fields
Label Description
Output Relay Summary
Output Id The output relay identification
Name The name of the output relay
Type The output type is digital
Admin The administrative state of the alarm output relay
When the digital output relay output state is set to no
shutdown, the normally closed contacts open and the
normally open contacts close. The digital output displays
a digital output administrative status of up and the state
of active (the output relay is energized).
When the digital output relay output state is set to
shutdown, the normally closed contacts close and the
normally open contacts open. The digital output displays
a digital output administrative status of down and the
state of off (the output relay is not energized).
State The current state of the alarm output relay:
ghost: no equipment is installed
off: the output relay is not energized (it is administratively
disabled)
active: the output relay is energized (active)
