7705 SAR Interfaces
634
Interface Configuration Guide
3HE 11011 AAAC TQZZA Edition: 01
Config Phy-tx-clock The mode used to establish timing control of a
1000Base-T port. The options are:
• N/A— the port does not support 1000Base-T
• auto-pref-master—prefers to be master during
autonegotiation
• auto-pref-slave—prefers to be slave during
autonegotiation
• slave—the port is forced to be slave
• master—the port is forced to be master
Oper Phy-tx-clock The operational value of the master-slave relationship of
the 1000Base-T physical layer transmit clock. The
options are:
• N/A— the port or the inserted SFP does not support
1000Base-T, the port is down, or negotiation failed
• slave—the port is slave
• master—the port is master
Allow Eth-BN Indicates whether Ethernet Bandwidth Notification (ETH-
BN) is allowed on the port: True or False
BN Egr.Rate in use The egress rate in use based on the request from the
ETH-BN server MEP
Eth-BN hold time The configured hold time (in seconds) between an egress
rate change based on a received Bandwidth Notification
Message (BNM) and the next change request that will be
accepted
Egress Rate The maximum amount of egress bandwidth (in kilobits
per second) that this Ethernet interface can generate
Ingress Rate The maximum amount of ingress bandwidth (in kilobits
per second) that this Ethernet interface can generate
Down-when-looped Enabled: The down-when-looped feature is enabled on
the port
Disabled: The down-when-looped feature is disabled on
the port
Keep-alive The time interval between keepalive PDUs transmitted
toward the network during loop detection by the
down-when-looped feature
Loop Detected Indicates whether a loop is detected on the port
Table 59 Show PoE Port Output Fields (Ethernet) (Continued)
Label Description
