Single Fiber Mode Yes: single fiber mode
No: not single fiber mode
Ing. Pool % Rate The amount of ingress buffer space, expressed as a
percentage of the available buffer space, that will be
allocated to the port for ingress buffering
Egr. Pool % Rate The amount of egress buffer space, expressed as a
percentage of the available buffer space, that will be
allocated to the port for egress buffering
Clock Source node: the link uses the internal clock when transmitting data
loop: the link recovers the clock from the received data
stream
Framing sonet: the port is configured for SONET framing
sdh: the port is configured for SDH framing
Last State Change The last time that the operational status of the port changed
state
Port IfIndex The interface’s index number, which reflects its initialization
sequence
Last Cleared Time The time since the last clear
DDM Events Enabled: digital diagnostic monitoring events is enabled for
the port
Disabled: digital diagnostic monitoring events is disabled for
the port
J0 String The section trace value that is sent to the far-end port
Section Trace Mode byte: the section trace in the SONET section header is set in
bytes
string: a text string is used to identify the SONET section
header
increment-z0: an incremental STM ID is configured instead
of a static value
Rx S1 Byte The synchronization status message value of the received
SONET/SDH S1 byte
Rx K1/K2 Byte The value of the received SONET/SDH K1/K2 byte
Tx S1 Byte The synchronization status message value of the
transmitted SONET/SDH S1 byte
Table 66 Show Port Detail Output Fields (SONET/SDH Port) (Continued)
