Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 695
Single Fiber Mode Yes: single fiber mode
No: not single fiber mode
IfIndex The interface’s index number, which reflects its
initialization sequence
Hold time up The link-up dampening time in seconds
The port link dampening timer value that reduces the
number of link transitions reported to upper layer
protocols
Last State Change The last time that the operational status of the port
changed state
Hold time down The link-down dampening time in seconds. The down
timer controls the dampening timer for link down
transitions.
Last Cleared Time The time since the last clear
DDM Events Enabled: digital diagnostic monitoring events is enabled
for the port
Disabled: digital diagnostic monitoring events is disabled
for the port
Configured Mode network: the port is configured for transport network use
access: the port is configured for service access
Encap Type null: ingress frames will not use any tags or labels to
delineate a service
dot1q: ingress frames carry 802.1Q tags, where each tag
signifies a different service
null&dot1q: applies only to port 1 and port 2 on the 2-port
10GigE (Ethernet) Adapter card and 2-port 10GigE
(Ethernet) module. The encapsulation type for these
ports is not user-configurable.
Dot1Q Ethertype The protocol carried in a dot1q Ethernet frame
VLAN Filter The filter ID of the VLAN filter
Ing. Pool % Rate The amount of ingress buffer space, expressed as a
percentage of the available buffer space, that will be
allocated to the port for ingress buffering
Table 71 Show Port Detail Output Fields (Ring Ethernet) (Continued)
Label Description
