7705 SAR Interfaces
696
Interface Configuration Guide
3HE 11011 AAAC TQZZA Edition: 01
Egr. Pool % Rate The amount of egress buffer space, expressed as a
percentage of the available buffer space, that will be
allocated to the port for egress buffering
Net. Egr. Queue Pol. The number of the associated network egress queue
QoS policy, or default if the default policy is used
Net. Scheduler Mode The mode for servicing CoS queues; 16-priority
scheduling is the only supported value
Auto-negotiate true: the link attempts to automatically negotiate the link
speed and duplex parameters
false: the duplex and speed values are used for the link
MDI/MDX Ethernet type
Config Phy-tx-clock The mode used to establish timing control of a
1000Base-T port. The options are:
• N/A— the port does not support 1000Base-T
• auto-pref-master—prefers to be master during
autonegotiation
• auto-pref-slave—prefers to be slave during
autonegotiation
• slave—the port is forced to be slave
• master—the port is forced to be master
Oper Phy-tx-clock The operational value of the master-slave relationship of
the 1000Base-T physical layer transmit clock. The
options are:
• N/A— the port or the inserted SFP does not support
1000Base-T, the port is down, or negotiation failed
• slave—the port is slave
• master—the port is master
Egress Rate The maximum amount of egress bandwidth (in kilobits
per second) that this Ethernet interface can generate
Ingress Rate The maximum amount of ingress bandwidth (in kilobits
per second) that this Ethernet interface can generate
Ingress CBS (bytes) Indicates the ingress committed buffer space
Src-pause A notification to slow down the transmission rate when it
exceeds the bandwidth limit
LACP Tunnel Indicates whether LACP packet tunneling is enabled
Table 71 Show Port Detail Output Fields (Ring Ethernet) (Continued)
Label Description
