Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 697
Down-when-looped Enabled: The down-when-looped feature is enabled on
the port
Disabled: The down-when-looped feature is disabled on
the port
Keep-alive The time interval between keepalive PDUs transmitted
toward the network during loop detection by the
down-when-looped feature
Loop Detected Indicates whether a loop is detected on the port
Retry The minimum wait time before the port is re-enabled after
it is brought down due to a loop detection
Use Broadcast Addr Indicates whether the down-when-looped feature has
been configured to compare the destination MAC
address of received PDUs to the broadcast MAC address
instead of the MAC address of the port
Loopback The type of loopback configured on the port, either line,
internal, or none
Swap Mac Addr. Indicates whether MAC address swapping is enabled
Loopback Time Left The number of seconds left in a timed loopback
If there is no loopback configured or the configured
loopback is latched, the value is unspecified.
If configured loopback is persistent, the value persistent
Cfm Loopback Indicates whether the CFM loopback is high priority, low
priority, dot1p, or disabled
Cfm Loopback Vlan Indicates the VLAN IDs for VLANs that have a CFM
loopback enabled
Sync. Status Msg. Indicates whether Synchronization Status Messaging is
enabled on the port
Rx Quality Level The Synchronization Status Messaging quality level
value received on the port
PTP Asymmetry Indicates whether PTP asymmetry is enabled
Edge Timestamp Indicates whether the edge timestamp is enabled
Timestamp Capable Indicates whether the port is timestamp-capable
Code-Type The Synchronization Status Messaging quality level code
type, either SONET or SDH
Table 71 Show Port Detail Output Fields (Ring Ethernet) (Continued)
Label Description
