7705 SAR Interfaces
698
Interface Configuration Guide
3HE 11011 AAAC TQZZA Edition: 01
Configured Address The base chassis Ethernet MAC address
Hardware Address The interface hardware- or system-assigned MAC
address at its protocol sublayer
Cfg Alarm The type of alarms to be logged and reported for the port
Alarm Status The current alarm state
Traffic Statistics
Octets Input/Output The total number of octets received and transmitted on
the port
Packets Input/Output The number of packets, delivered by this sublayer to a
higher (sub) layer, which were not addressed to a
multicast or broadcast address at this sublayer. The total
number of packets that higher-level protocols requested
be transmitted, and which were not addressed to a
multicast or broadcast address at this sublayer, including
those that were discarded or not sent.
Errors Input/Output For packet-oriented interfaces, the number of inbound
packets that contained errors preventing them from being
deliverable to a higher-layer protocol. For character-
oriented or fixed-length interfaces, the number of inbound
transmission units that contained errors preventing them
from being deliverable to a higher-layer protocol.
For packet-oriented interfaces, the number of outbound
packets that could not be transmitted because of errors.
For character-oriented or fixed-length interfaces, the
number of outbound transmission units that could not be
transmitted because of errors.
Ethernet Statistics
Broadcast Pckts The number of packets, delivered by this sublayer to a
higher (sub) layer, which were not addressed to a unicast
or multicast address at this sublayer. The total number of
packets that higher-level protocols requested be
transmitted, and which were not addressed to a unicast
or multicast address at this sublayer, including those that
were discarded or not sent.
Table 71 Show Port Detail Output Fields (Ring Ethernet) (Continued)
Label Description
