7705 SAR Interfaces
708
Interface Configuration Guide
3HE 11011 AAAC TQZZA Edition: 01
Cfm Loopback Indicates whether the CFM loopback is high priority, low
priority, dot1p, or disabled
Sync. Status Msg. Indicates whether Synchronization Status Messaging is
enabled on the port
Rx Quality Level The Synchronization Status Messaging quality level
value received on the port
PTP Asymmetry Indicates whether PTP asymmetry is enabled
Edge Timestamp Indicates whether the edge timestamp is enabled
Timestamp Capable Indicates whether the port is timestamp-capable
CRC Mon SD Thresh Indicates the CRC signal degrade threshold value (1 to
9), if enabled
CRC Mon SF Thresh Indicates the CRC signal fail threshold value (1 to 9), if
enabled
CRC Mon Window Indicates the CRC window sampling size value (5 to 60)
Configured Address The base chassis Ethernet MAC address
Hardware Address The interface hardware- or system-assigned MAC
address at its protocol sublayer
Cfg Alarm The type of alarms to be logged and reported for the port
Alarm Status The current alarm state
Traffic Statistics
Octets Input/Output The total number of octets received and transmitted on
the port
Packets Input/Output The number of packets, delivered by this sublayer to a
higher (sub) layer, which were not addressed to a
multicast or broadcast address at this sublayer. The total
number of packets that higher-level protocols requested
be transmitted, and which were not addressed to a
multicast or broadcast address at this sublayer, including
those that were discarded or not sent.
Table 72 Show Port Detail Output Fields (v-port) (Continued)
Label Description
