Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 707
BN Egr.Rate in use The egress rate in use based on the request from the
ETH-BN server MEP
Eth-BN hold time The configured hold time (in seconds) between an egress
rate change based on a received Bandwidth Notification
Message (BNM) and the next change request that will be
accepted
Egress Rate The maximum amount of egress bandwidth (in kilobits
per second) that this Ethernet interface can generate
Ingress Rate The maximum amount of ingress bandwidth (in kilobits
per second) that this Ethernet interface can generate
Ingress CBS (bytes) Indicates the ingress committed buffer space
Src-pause A notification to slow down the transmission rate when it
exceeds the bandwidth limit
LACP Tunnel Indicates whether LACP packet tunneling is enabled
Down-when-looped Enabled: The down-when-looped feature is enabled on
the port
Disabled: The down-when-looped feature is disabled on
the port
Keep-alive The time interval between keepalive PDUs transmitted
toward the network during loop detection by the
down-when-looped feature
Loop Detected Indicates whether a loop is detected on the port
Retry The minimum wait time before the port is re-enabled after
it is brought down due to a loop detection
Use Broadcast Addr Indicates whether the down-when-looped feature has
been configured to compare the destination MAC
address of received PDUs to the broadcast MAC address
instead of the MAC address of the port
Loopback The type of loopback configured on the port, either line,
internal, or none
Swap Mac Addr. Indicates whether MAC address swapping is enabled
Loopback Time Left The number of seconds left in a timed loopback
If there is no loopback configured or the configured
loopback is latched, the value is unspecified.
If configured loopback is persistent, the value persistent
Table 72 Show Port Detail Output Fields (v-port) (Continued)
Label Description
