7705 SAR Interfaces
814
Interface Configuration Guide
3HE 11011 AAAC TQZZA Edition: 01
Id State State State Links Active Links
-------------------------------------------------------------------------------
bundle-ima-1/6.3 ima-grp Down Down Ghost 1 0/0
-------------------------------------------------------------------------------
Bundles : 1
===============================================================================
*A:ALU-1>
Note: The ima-grp command shows all bundles in the IMA group. The bundle-ima
command shows information on the specified bundle. The fields for both commands are the
same.
Table 110 Show Multilink Bundle IMA Group Output Fields
Label Description
Bundle Id The port ID for this bundle
Type The type of this multilink bundle:
ima: the bundle is of type IMA group
Admin State Up: the bundle is administratively up
Down: the bundle is administratively down
Oper State Up: the bundle is operationally up
Down: the bundle is operationally down
Port State The state level of the port:
none: the port is either in its initial creation state or is just
about to be deleted
ghost: no member links are configured as part of this
bundle
down: all member links are in “none”, “ghost”, or “down”
state
linkUp: at least one member link is in port state “link up”
but the bundle protocol is not yet operationally up (due to
the bundle protocol still coming up; for example, due to
insufficient number of member links in “link up” state yet
or to bundle being shut down)
Up: the bundle is ready to pass some kinds of traffic as
the bundle protocol has come up (at least “minimum
links” member links are in the port state up and the
bundle protocol is up)
