6 Operating status messages

BU 0200 en-3118 235

Pos: 68 2 /Anlei tung en/El ektr onik/FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Mel dung en Eins ch alts per re ( Tab ell enü ber schri ft) @ 3\ mod_1361803467385_388.docx @ 59922 @ 5 @ 1

Switch-on block messages

Display in the

SimpleBox /

ControlBox

Reason:

Text in the ParameterBox

Cause

• Remedy

Group Details in

P700 [-03]

Pos: 683 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Inf or mati on I 000 _01 [S K 18 0E ... SK 5 xxE] @ 2\mod_1347457775195_388.docx @ 47347 @ @ 1

I000

0.1 Disable voltage from IO

If the function "disable voltage"is parameterised, input (P420

/ P480) is at Low

•

Set "input High"

•

Check signal cable (broken cable)

0.2 IO fast stop

If the function "fast stop"is parameterised, input (P420 /

P480) is at Low

• Set "input High"

• Check signal cable (broken cable)

0.3 Block voltage from bus

• For bus operation (P509): control word Bit 1 is

"Low"

0.4 Bus fast stop

• For bus operation (P509): control word Bit 2 is

"Low"

0.5 Enable on start

Enable signal (control word, Dig I/O or Bus I/O) was already

applied during the initialisation phase (after mains "ON", or

control voltage "ON"). Or electrical phase is missing.

•

Only issue enable signal after completion of

initialisation (i.e. when the FI is ready)

•

Activation of "Automatic Start" (P428)

0.6 – 0.7 Reserved

Information message for PLC  see supplementary

instructions

Pos: 684 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Inf or mati on I 000 _02-Erg änz ung 08 und 09 [ SK 1 80E ... SK 5 xxE] @ 10\mod_1455725649528_388.docx @ 306332 @ @ 1

0.8 Right direction blocked

Switch-on block with inverter shut-off activated by:

P540 or by "Enable right block" (P420 = 31, 73) or "Enable

left block" (P420 = 32, 74),

The frequency inverter switches to "Ready for switching on"

status

0.9 Left direction blocked

Pos: 685 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Inf or mati on I 006 [SK 180E . .. SK 5xxE ] @ 2 \mod_1347457929759_388.docx @ 47372 @ @ 1

I006

6.0 Charging error

Charging relay not energised, because:

•

Mains / link voltage too low

•

Mains failure

•

Evacuation run activated ((P420) / (P480))

Pos: 68 6 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ung en z um B etr iebs zus ta nd/S tör mel dung en (Auf list ung )/I nfor ma tio n I0 11 [S K 1 80E . .. SK 5 xxE ] @ 2\ mod_1347457936856_388.docx @ 47397 @ @ 1

I011

11.0 Analog Stop

If an analog input of the frequency inverter or a connected

IO extension is configured to detect cable breaks (2-10V

signal or 4-20mA signal), the frequency inverter switches to

the status "ready for switch-on" if the analog signal

undershoots the value 1 V or 2 mA

This also occurs if the relevant analog input is

parameterised to function "0" ("no function").

• Check connections

Pos: 687 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Inf or mati on I 014 "res erviert" [SK 200 E ... SK 5xx E] @ 2\mod_1347457944329_388.docx @ 47422 @ @ 1

I014

14.4 Reserved

Error message for POSICON  see supplementary

instructions

Pos: 688 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Inf or mati on I 018 "reser viert" [SK 2xxE/ SK 5xxE/ SK 2xxE-FD S] @ 2\mod_1347457946544_388.docx @ 47447 @ @ 1

I018

18.0 Reserved

Information message for "Safe Stop" function  see

supplementary instructions

Pos: 68 9 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ungen zum Betr iebsz usta nd/Stör mel dung en (Aufli stung )/I nfor ma tio n - Ken nzeic hnung "Nicht ber eit" @ 20\mod_1513067472948_388.docx @ 2375129 @ @ 1

Indication of operating mode (message) on the

ParameterBox

or virtual operating unit of the

NORD CON-Software

: "Not ready"
