4-6 Installing the OSP cables
AccessNode 323-3001-210 Issue 1.0
Procedure 4-1 (continued)
Pulling the OSP cabling into the cabinet
Step Action
9 Perform the steps shown in Table 4-3 for the fiber entrance arrangement
dictated by the job specifications.
10 Secure the cable in an out-of-the-way position.
—continued—
Table 4-3
Pulling the OSP fiber into the cabinet
If the job specifications
require that the OSP
fiber cable is to be Then perform these steps
Spliced, grounded and
bonded in a location
external to the S800A
cabinet
• Protect the entire length of the fiber patch cords with
split flex tubing, or by using standard local practices
prior to pulling them into the cabinet.
• Pull the protected fiber patch cords from the external
source into the cabinet through the conduit opening
located on the far right-hand side of the termination
compartment (see Figure 4-1 on page 4-7).
• Tie wrap the protective tubing, with the patch cords
inside, to the rungs of the cable ladder on the right
hand side of the termination compartment.
• Go to step 10.
Spliced, grounded and
bonded at a fiber
management system
internal to the S800A
cabinet
• Pull the OSP fiber cable into the cabinet through the
conduit opening located on the far right-hand side of
the termination compartment
(see Figure 4-1 on page 4-7).
Note:
Splicing, bonding and grounding will be done at
the fiber management system (see Chapter 7,
“Routing and splicing the fiber cable”).
• Go to step 10.
Spliced at the fiber
management system and
bonded and grounded at
the termination
compartment in the
S800A cabinet
• Pull the OSP fiber cable into the cabinet through the
conduit opening located on the far right-hand side of
the termination compartment
(see Figure 4-1 on page 4-7).
Note:
Bonding and grounding procedures are in
Procedure 4-3 and Procedure 4-4 of this practice.
Splicing will be done at the fiber management system
(see Chapter 7, “Routing and splicing the fiber cable”).
• Go to step 10.
