7-8 Routing and splicing the fiber cable
AccessNode 323-3001-210 Issue 1.0
Procedure 7-1 (continued)
Routing the OSP fiber cable directly to the FPP
Step Action
3 Route cables across the ceiling of the cabinet on the rear side of the air baffle
according to the type of roof assembly (see Figure 7-2 or Figure 7-3).
Note 1:
For the heat exchanger roof, route the fiber inside the V-baffle
enclosure (see Figure 7-2 on page 7-9).
Note 2:
The air induction roof has a cable hooks for all cable routing (see
Figure 7-3 on page 7-9).
4 Tie wrap the fiber cable to the cabinet ceiling according to the type of roof
assembly.
—continued—
