Cabinet maintenance operations 12-37
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 12-8 (continued)
Connecting emergency standby power - attached ac power pedestal option
Figure 12-7
View of the ac compartment with an attached power pedestal
FW-15167
—end—
Front view
(Shown with
doors removed)
Customer/site
provided
meter socket
Transfer
knife switch
AC compartment
ground bar
Ground
Emergency
generator
connector
NORMAL
SERVICE
DISCONNECT
AC POWER
EMERGENCY
CB5
CB6
CB1
CB2
CB3MAIN
CB4
Power meter
and hub
FW-15167
