G3 Series EtherNet/IP
TM
DLR Technical Manual
15-152
TDG3EDM1-6EN 3/18
Subject to change without notice
www.asco.com/g3
Example No. 3 Table Data -SINT with Status”
Output Table
BYTE
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Valve Coil
No. 7
Valve Coil
No. 6
Valve Coil
No. 5
Valve Coil
No. 4
Valve Coil
No. 3
Valve Coil
No. 2
Valve Coil
No. 1
Valve Coil
No. 0
1
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Valve Coil
No. 11
Valve Coil
No. 10
Valve Coil
No. 9
Valve Coil
No. 8
2
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
3
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Status Table
BYTE
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
(Optional)
Comm.
Module
Diagnostic Bit
Comm.
Module
Diagnostic Bit
Comm.
Module
Diagnostic Bit
Comm.
Module
Diagnostic Bit
Comm.
Module
Diagnostic Bit
Comm.
Module
Diagnostic Bit
Comm.
Module
Diagnostic Bit
Comm.
Module
Diagnostic Bit
1
(Optional)
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
Sub-bus
Diagnostic Bit
2
(Optional)
Coil No. 7
Status
Coil No. 6
Status
Coil No. 5
Status
Coil No. 4
Status
Coil No. 3
Status
Coil No. 2
Status
Coil No. 1
Status
Coil No. 0
Status
3
(Optional)
Coil No. 15
Status
Coil No. 14
Status
Coil No. 13
Status
Coil No. 12
Status
Coil No. 11
Status
Coil No. 10
Status
Coil No. 9
Status
Coil No. 8
Status
4
(Optional)
Coil No. 23
Status
Coil No. 22
Status
Coil No. 21
Status
Coil No. 20
Status
Coil No. 19
Status
Coil No. 18
Status
Coil No. 17
Status
Coil No. 16
Status
5
(Optional)
Coil No. 31
Status
Coil No. 30
Status
Coil No. 29
Status
Coil No. 28
Status
Coil No. 27
Status
Coil No. 26
Status
Coil No. 25
Status
Coil No. 24
Status
6
(Optional)
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Allocated and
Reserved
Power Status
for Conn. D
Power Status
for Conn. C
Power Status
for Conn. B
Power Status
for Conn. A
7
(Optional)
High Alarm
for Conn. D
Low Alarm for
Conn. D
High Alarm
for Conn. C
Low Alarm for
Conn. C
High Alarm for
Conn. B
Low Alarm for
Conn. B
High Alarm
for Conn. A
Low Alarm for
Conn. A
8
(Optional)
Power Status
for Conn. H
Power Status
for Conn. G
Power Status
for Conn. F
Power Status
for Conn. E
Power Status
for Conn. D
Power Status
for Conn. C
Power Status
for Conn. B
Power Status
for Conn. A
9
(Optional)
Power Status
for Conn. H
Power Status
for Conn. G
Power Status
for Conn. F
Power Status
for Conn. E
Power Status
for Conn. D
Power Status
for Conn. C
Power Status
for Conn. B
Power Status
for Conn. A
Input Table
BYTE
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Discrete Input
No. 7
Discrete Input
No. 6
Discrete Input
No. 5
Discrete Input
No. 4
Discrete Input
No. 3
Discrete
Input No. 2
Discrete Input
No. 1
Discrete
Input No. 0
1
Discrete Input
No. 15
Discrete Input
No. 14
Discrete Input
No. 13
Discrete Input
No. 12
Discrete Input
No. 11
Discrete
Input No. 10
Discrete Input
No. 9
Discrete
Input No. 8
2
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog Input
No. 1 (LSB)
3
Analog Input
No. 1 (MSB)
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
Analog
Input No. 1
4
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog Input
No. 2 (LSB)
5
Analog Input
No. 2 (MSB)
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
Analog
Input No. 2
6
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog Input
No. 3 (LSB)
7
Analog Input
No. 3 (MSB)
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
Analog
Input No. 3
8
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog Input
No. 4 (LSB)
9
Analog Input
No.4 (MSB)
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
Analog
Input No. 4
10
Discrete Input
No. 7
Discrete Input
No. 6
Discrete Input
No. 5
Discrete Input
No. 4
Discrete Input
No. 3
Discrete
Input No. 2
Discrete Input
No. 1
Discrete
Input No. 0
11
Discrete Input
No. 15
Discrete Input
No. 14
Discrete Input
No. 13
Discrete Input
No. 12
Discrete Input
No. 11
Discrete
Input No. 10
Discrete Input
No. 9
Discrete
Input No. 8
