Nvidia JETSON NANO Product Design Guide

NVIDIA Jetson Nano DG-09502-001_v2.1 | 4
Chapter 2. Jetson Nano
The Jetson Nano resides at the center of the embedded system solution and includes the
following:
 Power (PMIC/Regulators, etc.)
 DRAM (LPDDR4)
 eMMC
 Gigabit Ethernet Controller
 Power Monitor
In addition, a wide range of interfaces are available at the main connector for use on the
carrier board as shown Table 2-1 and Figure 2-1.
Table 2-1. Jetson Nano Interfaces
Category
Function
Category
Function
USB
USB 2.0 Interface (3x) LAN Gigabit Ethernet
USB 3.0 (1x) I2C 4x
PCIe PCIe (x1/2/4) UART 3x
Camera
CSI (3 x4 or 2 x4 + 2 x2 or 1 x4 + 3 x2), Control,
Clock
SPI 2x
Display
eDP/DP (see Note 1) Wi-Fi/BT/Modem PCIe/UART/I2S, Control/handshake
HDMI/DP Interface (w/CEC) Fan FAN PWM and Tach Input
DSI (1, 2-lane), Display/Backlight Control Debug JTAG test points on module and UART
Audio I2S Interface (2x) and Clock System Power Control, Reset, alerts
SD Card/SDIO SD Card or SDIO Interface (1x) Power Main Input and battery back-up for RTC
Note: DP on eDP interface does not support HDCP or Audio

Nvidia JETSON NANO Specifications

General

GPU	128-core NVIDIA Maxwell
Memory	4 GB LPDDR4
Storage	16 GB eMMC 5.1
Video Encode	4K @ 30 | 4x 1080p @ 30 | 9x 720p @ 30 (H.264/H.265)
Dimensions	100 mm x 80 mm x 29 mm
CPU	Quad-core ARM Cortex-A57
Video Decode	4K @ 60 | 2x 4K @ 30 | 8x 1080p @ 30 | 18x 720p @ 30 (H.264/H.265)
Connectivity	Gigabit Ethernet
Display	HDMI 2.0
USB	USB 3.0
Other	GPIO, I2C, SPI, UART
Operating System	Linux
Power	5V
Camera	12x (MIPI CSI-2) DPHY lanes
