Nvidia JETSON NANO Product Design Guide

NVIDIA Jetson Nano DG-09502-001_v2.1 | 1
Chapter 1. Introduction
This design guide contains recommendations and guidelines for engineers to follow in
creating a product that is optimized to achieve the best performance from the common
interfaces supported by the NVIDIA
®
Jetson Nano
™
System-on-Module (SOM).
This design guide provides detailed information on the capabilities of the hardware module,
which may differ from supported configurations by provided software. Refer to software
release documentation for information on supported capabilities.
Note: Most of the interface usage noted in this design guide is based on the NVIDIA developer kit
carrier board design.
1.1 References
Refer to the following list of documents or models for more information. Always use the latest
revision of all documents.

Jetson Nano Module Data Sheet
 Tegra X1 (SoC) Technical Reference Manual
 Jetson Nano Developer Kit Carrier Board Specification
 Jetson Nano Module Pinmux
 Jetson Nano Thermal Design Guide
 Jetson Nano Developer Kit Carrier Board Design Files
 Jetson Nano Developer KIt Carrier Board BOM
 Jetson Nano SCL (Supported Component List)

Nvidia JETSON NANO Specifications

General

GPU	128-core NVIDIA Maxwell
Memory	4 GB LPDDR4
Storage	16 GB eMMC 5.1
Video Encode	4K @ 30 | 4x 1080p @ 30 | 9x 720p @ 30 (H.264/H.265)
Dimensions	100 mm x 80 mm x 29 mm
CPU	Quad-core ARM Cortex-A57
Video Decode	4K @ 60 | 2x 4K @ 30 | 8x 1080p @ 30 | 18x 720p @ 30 (H.264/H.265)
Connectivity	Gigabit Ethernet
Display	HDMI 2.0
USB	USB 3.0
Other	GPIO, I2C, SPI, UART
Operating System	Linux
Power	5V
Camera	12x (MIPI CSI-2) DPHY lanes
