NVIDIA Jetson Nano DG-09502-001_v2.1 | 69
Chapter 13. Unused Interface Terminations
13.1 Unused Multi-purpose Standard CMPS
Pad Interfaces
The following Jetson Nano pins (and groups of pins) are Tegra MPIO pins that support either
special function IOs (SFIO) and/or GPIO capabilities. Any unused pins or portions of pin groups
listed in Table 13-1 that are not used can be left unconnected.
Table 13-1. Unused MPIO Pins and Pin Groups
Jetson Nano Pins and Pin Groups Jetson Nano Pins and Pin Groups
FORCE_RECOVERY* SDMMC
GPIO00 I2S
PCIE0_CLK/RST/CLKREQ/WAKE UART
GPIO07, GPIO13, GPIO14 I2C
DP0_HPD, DP1_HPD, HDMI_CEC SPI
CAM Control, Clock
