Nvidia JETSON NANO Product Design Guide

Audio
NVIDIA Jetson Nano DG-09502-001_v2.1 | 55
Figure 10-1. Audio Codec Connection Example
Audio Codec
ALC5639
DCVDD
DBVDD
MICVDD
GPIO2/DMIC_ SCL
GPIO1/IRQ
M CL K
BCL K1
LRCK1
DACDAT1
ADCDAT1
BCL K2/ GPIO 3/P DM_S CL
LRCK2 /GP IO4/ PDM_SDA
DACDAT2/GPIO5_DMIC1_SCL
ADCDAT2/GPIO6/DMIC2_SDA
SDA
SCL
LO UTR /N
LO UTL /P
DGND
DACGND
CPGND
AG ND
AG ND 2
SP KVDDL
SP KVDDR
AV DD
AV DD 2
CPVDD
CPP1
CPN1
CPP2
CPN2
CPVP P
CPVE E
MICBIA S
SP 0_LP
SP 0_LN
SP 0_ RP
SP 0_ RN
IN1P
IN2P/INL/DMIC2_SDA/ JD3
HP0 _R
HP0 _L
MIC_IN_DE T
DACVREF
CPVRE F
VREF1
VREF2
SP KVREF
1uF
2. 2uF
VDD_5V
4.7uF 0.1uF4.7uF 4.7uF
25 Mil
(Virtual Short)
I2 Sx_FS
I2Sx_DOUT
I2Sx_DIN
I2 Sx_S CLK
Jet son N ano
I2 S0 or I2 S1
1uF
0.1uF2.2uF
0.1uF2.2uF
0.1uF10uF
Avail. Jetson Nano
GPIO (see note 1)
2.2uF
1uF
Jet son N ano GP IO0 9
(AUD_MCLK)
Jet son N ano I2 C
(see note 2)
I2 C2 _S DA
I2 C2 _S CL
0.1uF10uF VDD_1 V8
10uF10uF
12 0Ω
0.1uF0.1uF
10uF10uF
12 0Ω
2. 2uF
2. 2uF
2. 2uF
Audio Panel
Header
1
3
5
7
9
2
4
6
8
10
VDD_1V8
10kΩ
2.2 kΩ 2.2 kΩ
1MΩ 1MΩ
I N 1P
I N 2P
AUD_HPOR
SE N SE _S END
AUD_HPOL
GND
AUD_GP IO4
AUD_MIC_JD
Key
AUD_HP_JD
25 Mil
(Virtual Short)
Notes:
1.The Interrupt pin from the audio codec can connect to any available Jetson Nano GPIO. If the
pin must be wake-capable, choose one of the GPIOs that supports this function.
2.I2C2 supports 1.8V operation since the interface is pulled to 1.8V through 4.7kΩ resistors on
the module. If another I2C interface on Jetson Nano is used, a level shifter will be required as
all the others are 3.3V.
