NVIDIA Jetso n Nano DG-09502-001_v2.1 | ii
Document History
DG-09502-001_v2.1
1.0 June 7, 2019 Initial Release
2.0 March 2, 2020 •
Added MPIO pad code and POR columns to the pin description
tables through the design guide
• Added chapter on modular connector (Chapter 3)
• Updated power down figures (Figure 4-4 and Figure 4-5)
• Updated Figure 5-1 to show details of FET used as level shifter
for VBUS Detect to show it is inverted.
• Corrected USB2 module pin numbers in Figure 5-1
• Corrected PCIE0_TX3/RX0 pin numbers in Figure 5-7
• Updated the notes to the PCIe signal routing requirements
table (Table 5-9)
• Updated Gigabit Ethernet controller in Section 5.3
• Updated Figure 7-1 to “4 Lanes…”
2.1 July 1, 2020
• Added Chapter 3 “Developer Kit Feature Considerations”
• Updated notes for all pin description tables
• Corrected module pin numbers in Figure 7-2
• Updated Table 9-1 include both 1.8V and 3.3V pins, since the
pins are associated with a rail that may be set to one or the
other voltage
• Updated Figure 9-1 to change SDMMC_SD to connect to
generic GPIO
• Removed GPIO08 for SD Card Detect from Table 9-3 since
figure shows generic GPIO
• Updated Table 11-6 to mention buffer on module
• The Jetson Nano pin description and design checklist are now
attachments to this design guide
