Olympus RollerFORM - 6.8 Changing the Mini-Wheel Encoder

DMTA-20073-01EN, Rev. C, November 2015
Chapter 6 110
Figure 6-37 Installing the probe’s angle-adjustment components
6.8 Changing the Mini-Wheel Encoder
The Mini-Wheel encoder’s primary location on the RollerFORM is under the frame
and over the rear roller. The encoder can be changed if necessary.
To change the Mini-Wheel encoder, see the following sections:
• “Removing the Mini-Wheel Encoder from the Rear Roller” on page 111
• “Installing the Mini-Wheel Encoder on the Rear Roller” on page 121
To relocate the Mini-Wheel encoder to its primary location, see “Relocating the Mini-
Wheel Encoder on the Acoustic Wheel” on page 125.
Angle-adjustment arm
Angle-adjustment knob
Spring-lock washer
Angle cursor
