Olympus RollerFORM - Figure 2-1 an Omniscan Instrument with Rollerform Cables Connected

DMTA-20073-01EN, Rev. C, November 2015
Chapter 2 30
Figure 2-1 An OmniScan instrument with RollerFORM cables connected
2. Connect the OmniScan probe connector to the instrument.
When connecting the LEMO encoder connector to an OmniScan MX or to a TomoScan
FOCUS series instrument, an adaptor is required. For more information, see
“Connector Reference” on page 140.
OmniScan probe connectorLEMO encoder connector
