Olympus RollerFORM - Figure 3-1 the Open out Valve on the Flange

DMTA-20073-01EN, Rev. C, November 2015
Chapter 3 42
Figure 3-1 The open OUT valve on the flange
2. Connect the feeding tube adaptor to the IN check valve, which is also located on
the acoustic wheel flange on the probe-cable side (see Figure 3-2 on page 43).
Loosened OUT valve
