DMTA-20073-01EN, Rev. C, November 2015
Maintenance 85
Figure 6-13 Probe cable extending from the front to the rear end of the
RollerFORM handle
5. Install the acoustic wheel on the RollerFORM.
For more information, see “Installing the Acoustic Wheel on the RollerFORM
Scanner” on page 107.
6.4 Cleaning the Liquid Chamber
When the liquid chamber of the RollerFORM’s acoustic wheel is filled with water, it
must be periodically cleaned of contaminants, such as algae, dirt, or mold, that may
accumulate over time.
Length of 25 cm (10 in.) of probe cable
extending from rear end of scanner handle
