Olympus RollerFORM - Figure 1-5 the 1.0 L Manual Pump and Feeding Tube

DMTA-20073-01EN, Rev. C, November 2015
Chapter 1 24
Figure 1-5 The 1.0 L manual pump and feeding tube
Olympus highly recommends filling the liquid chamber with noncorrosive glycol,
distilled water, or deionized water, depending on the inspection conditions. For more
information, see “Choosing a Liquid to Fill the Chamber” on page 39.
Nozzle
Trigger lock
Trigger
Handle
Tank
Valve
Feeding tube
Feeding tube adaptor
Piston
Piston
Filter
