DMTA-20073-01EN, Rev. C, November 2015
RollerFORM Scanner Overview 25
Before filling the acoustic wheel’s liquid chamber with water, , let the water stand in
the the manual pump for a few hours to allow the air dissolved in it to be released.
When manipulating noncorrosive glycol while operating the RollerFORM, the safety
measures found in the product’s MSDS must be applied. For more information, see
“Safety” on page 9.
To apply water couplant on the surface to inspect
1. Make sure that the feeding tube’s valve is closed (Figure 1-6 on page 25).
Figure 1-6 The feeding tube valve in the closed position
2. If necessary, fill the manual pump’s tank with water.
CAUTION
