DMTA-20073-01EN, Rev. C, November 2015
Preparing the RollerFORM Liquid Chamber
43
Figure 3-2 Connecting the feeding tube adaptor to the IN check valve
3. Open the valve on the manual pump’s feeding tube (see Figure 3-3 on page 44).
Make sure that the trigger at the top of the pump is not engaged (see Figure 3-4 on
page 45).
Do not pressurize the glycol or water in the manual pump. Doing so would increase
the quantity of air dissolved into the liquid and consequently the amount of degassing
time required for the acoustic wheel’s liquid chamber would also be increased.
IN check valve Feeding tube adaptor
