Olympus RollerFORM - 7 Specifications; General Specifications; Environment Specifications; Table 3 General Specifications

DMTA-20073-01EN, Rev. C, November 2015
Specifications 139
7. Specifications
This chapter contains the specifications for the RollerFORM scanner.
7.1 General Specifications
Table 3 on page 139 provides the RollerFORM’s general specifications.
7.2 Environment Specifications
Table 4 on page 140 provides the RollerFORM’s operating environment specifications.
Table 3 General specifications
Description Va lu e
Typical near surface resolution (3 mm × 3 mm
[0.12in.×0.12in.]delamination)
1 mm at 5 MHz, 1.5 mm at
3.5 MHz
Position of repeat interface echo (in composite) 50 mm (1.97 in.)
Minimum surface curvature (convex radius) 50 mm (1.97 in.)
Dimensions (L × W × H) 235 mm × 145 mm × 150 mm
(9.25in.×5.71in.×5.91in.)
Weight (without liquid) 1.5 kg (3.31 lb)
Encoder voltage 5V
Encoder current 25 mA maximum
