Olympus RollerFORM User Manual

DMTA-20073-01EN, Rev. C, November 2015
Spare Parts 145
7 Q8300221 2 O-RING ID-56MM OD-59MM W-1.5MM
8 Q8300225 10 CABLE TIE WRAP
9 Q8300195 4 SCREW M3X12MM HEX HEAD STAIN
10 Q8300183 1 SCREW M3X6MM HEX FLAT STAIN
11 U8779180 2 SCREW M3X6MM HEX HEAD STAIN
12 Q8300196 10 SCREW M3X6MM PHI FLAT STAIN WITH ORING
13 U8905961 4 M3 LOCK WASHER STAINLESS (DIN 127B)
14 Q8300197 2 SCREW M4X12MM HEX P-HEAD STAIN
15 U8902446 2 SPRING WASHER M4 STAIN
16 Q8300198 2 SCREW 6 PENX M5X10MM HEAD STAIN
17 U8900327 2 SPRING WASHER M5 STAIN
18
Q8300199 3 HEX S-SET SCREW M5X5MM STAIN WITH NYLON
TIP
19 Q8300200 1 STAINLESS STEEL BELLEVILLE 4MM
20 Q7750006 — ROLLERFORM-SP-LASER
21 Q7750003 — ROLLERFORM-SP-ENCODER
22 Q8300202 1 BLEED SCREW
23 Q7750001 — ROLLERFORM-SP-TIRE
24 Q8300203 1 SUPPORT PLATE ANGULAR SCREW
25 Q8300204 1 CENTRAL SKID PLATE WHEEL PROBE
26 Q8300205 1 PROBE NUT M4
27 U8906665 4 CABLE VELCRO 4 INCHES
— Q8300380 1 ROLLERFORM - RETAINING RING ASSEMBLY TOOL
28 Q8300201 1 THUMB SCREW M4 WITH PLASTIC TIP
29
Q1500286 — ROLLERFORM - LENGTH-6.7 FEET BLACK SPIRAL
WRAP DIA-3/4 INCHES (60BA5034)
30 Q8300189 — ROLLERFORM-SP-HANDLE
31 Q8300188 — ROLLERFORM - ADJUSTABLE WHEELS
Table 6 RollerFORM spare parts (continued)
Drawing
number
Item
number
Quantity
(included
in kit
KITX0409
[Q7750007])
Description
