Advanced Console Server & RIM Gateway User Manual 159
7.3.3 Perform RPC Action
 Click on Perform RPC Action as the Add Trigger Action. Enter a unique Action Name and set the Action
Delay Time
 Select a power Outlet and specify the Action to be performed (power On, OFF or Cycle)
 Click Save New Action
7.3.4 Run Custom Script
 Click on Run Custom Script as the Add Trigger Action. Enter a unique Action Name and set the Action Delay
Time
 Create a script file to execute when this action is triggered and enter the Script Executable file name e.g.
/etc/config/action.sh
 Set the Script Timeout (i.e. the maximum run-time for the script). Leave as 0 for unlimited.
 Enter any Arguments that are to be passed to the script and click Save New Action
7.3.5 Send SNMP Trap
 Click on Send SNMP Trap as the Add Trigger Action. Enter a unique Action Name and set the Action Delay
Time
Note: The SNMP Trap actions are valid for Serial, Environmental, UPS and Cellular data triggers only
7.3.6 Send Nagios Event
 Click on Send Nagios Event as the Add Trigger Action. Enter a unique Action Name and set the Action Delay
Time
 Edit the Nagios Event Message text to display on the Nagios status screen for the service
 Specify the Nagios Event State (OK, Warning, Critical or Unknown) to return to Nagios for this service
 Click Save New Action
Note: To notify the central Nagios server of Alerts, NSCA must be enabled under System: Nagios and Nagios must be
enabled for each applicable host or port
