Chapter 2: Installation
20 Console Server & RIM Gateway User Manual
2.1.6 SD4001 kit components
SD4001 Serial Device Server
Connector DB9F to RJ45 crossover
Universal Input 12 VDC Wall mount Power Supply
Quick Start Guide and CD-ROM
 Unpack your SD4001 and verify you have all the parts shown above, and that they all appear in good working
order
 Proceed to connect your SD4001 to the network, to the serial port of the controlled device and to power as
outlined below
2.1.7 ACM5000 kit components
Part # 509054
Part # 509055
Part # 509056
Part # 509057
Part # 509058
Part # 509059
Part # 509000
Part # 509073
ACM5002 Advanced Console Server
ACM5003-M
ACM5003-W
ACM5004
ACM5004-2
ACM5004-G
ACM5004-G-I
ACM5004-2-I
Part # 3190014 and
3190015
Cisco Connector DB9F-RJ45 straight and DB9F-RJ45
cross-over
Power Supply 12VDC 1.0A
Wall mount
Quick Start Guide and CD-ROM
 Unpack your ACM5000 kit and verify you have all the parts shown above, and that they all appear in good
working order. The ACM5004-G has an external 3G aerial to be attached.
 Proceed to connect your ACM5000 to the network, the serial ports of the controlled servers and AC power as
shown below
