Remove a Fan Module

Caution - When changing fan modules, note that only the fan modules can be removed or

replaced. Do not service any other components in the fan compartment unless the server is shut

down and the power cords are removed.

Install a new fan module.

See “Install a Fan Module” on page 86.

Related Information

■

“Extend the Server to the Service Position” on page 63

■

“Install a Fan Module” on page 86

Servicing Fan Modules 85
