Oval ALTI mass CA00A - Page 10

L
--
740
--
28
--
E
10
Acceptable fluids Hot water, Saturated steam, Overheated steam
Heat retention fluid max. output pressure 0.98MPa
Joint port for heat retention fluid φ10 stainless steel tube
Recommended joint Tube joint manufactured by Swagelok Company
●
High temperature service models (CA025 to CA080)
Item Description
Model
CA025
(high temperature service)
CA040
(high temperature service)
CA050
(high temperature service)
CA080
(high temperature service)
Nominal flange size 25mm, 1", DN25 40mm, 1・1/2", DN40 50mm, 2", DN50 80mm, 3", DN80
Materials
Wetted parts SUS316L
SUS316L
SUS316L＋Alloy C
Alloy C
Housing SUS304
Process connection JIS 10, 20, 30, 40, 63K RF / ASME（JPI） 150, 300, 600 RF / DIN PN 10, 16, 25, 40 RF
Acceptable fluids Liquid
Density range 0.3 to 2.0g/mL
Viscosity range Max.10000mPa・s
Temperature range (※1) －40 to ＋350℃ (Separately mounted only)
Tube withstands (at 20℃) 9.4MPa
Max. operating pressure
Varies according to process connection.
(※2)
Sensor housing withstands (※3) 1.6MPa 1.8MPa 1.4MPa
Flow direction Forward / Reverse
Explosionproof configuration Refer to section 10.4
Dusttight, waterproof configuration IP66 / 67
Heat Tracer Specifications (CA025 to CA080 Option)
NOTES ※1: Allowable ambient temperature permitted for the sensor unit is up to 50℃.
※2: Refer to section 3.1.5 for PED specification.
※3: This pressure does not represent the rated test pressure of a pressure vessel, but 1/4 of the breakdown
test pressure at OVAL (distorted enclosures do not constitute a failure of the test), or the data obtained
from the FEM analysis, whichever is lower (or safer).
※: For availability of high pressure gas safety regulation compliant and CE mark compliant products, consult
the factory.
※: Only separately mounted transmitter is applicable.
●
High temperature service models (CA100, CA150)
Item Description
Model CA100 (high temperature service) CA150 (high temperature service)
Nominal flange size 100mm, 4", DN100 150mm, 6", DN150
Materials
Wetted parts SUS316L
Housing SUS304
Process connection JIS 10, 20, 30K RF / ASME（JPI） 150, 300, 600 RF / DIN PN 10, 16, 25, 40 RF
Acceptable fluids Liquid
Density range 0.3 to 2.0g/mL
Viscosity range Max.10000mPa・s
Temperature range －40 to ＋350℃
(※1)
Tube withstands (at 20℃) 13.5MPa
Max. operating pressure
Varies according to process connection.
(※2)
Flow direction Forward / Reverse
Explosionproof configuration Refer to section 10.4
Dusttight, waterproof configuration IP66 / 67
NOTES ※1: Max. ambient temperature of the sensor unit is 50℃.
※2: Refer to section 3.1.5 for PED specification.
※: For products that are compliant with the High Pressure Gas Safety Act, consult OVAL.
※: Only separately-mounted transmitter is applicable.
