■ ITRI explosionproof
The cable gland is not attached to the electric wire connection port. Please prepare it at customer’s side.
In addition, the specifications for usable cable gland are as follows;
Integral Type Converter
Separate Type Converter
Usable Cable Gland
・Conformance Certification : The cable gland should be the one which passed explosion-proof
verification in domestic Taiwan.
・Explosion-proof Notation : Ex d ⅡC Gb
・Screw Joint Part : G3/4
・IP Protection Class : Greater than IP66/67
・Operating Temperature Range : －40℃ to +60℃
〈Caution Points〉
◆ Use the cable gland with minimum of 5 screw threads engaged when connecting the cable gland to
the converter electric connection part.
◆ Seal off properly not to make the infiltration of rain water and dust from cable, rubber packing, screw
tightening part and so on.
