14-12
FP0
Item
Add-
ress
Name
Default
value
Descriptions
410
Unit No. setting for tool
port (when connecting C-
NET)
1
(K1)
1 to 32 (K1 to K32)
411
Communication format
setting for tool port
Modem:
Disabled
Data
length:
8 bits
(H0)
Using FPWIN GR
Modem: Disable/Enable
Data length: 7 bits/8 bits
Using FP programmer II
Specify the setting contents using H
constants.
When connecting a modem, set the
unit number to 1 with system register
410.
Tool
port
setting
414
Baud rate
setting
Setting by
program
ming tool
software
9600
(H0)
0: 9600 bps
1: 19200 bps
Tool
port/
RS232C
port
setting
414
Baud rate
setting for
tool port and
RS232C port
Setting by
FP pro-
grammer
II
H1
If 19200 bps is set for both the tool
port and RS232C port, H100 should
be written.
