Name Boolean Operand Description Steps
Screen display instructions
F180
FP-e screen
display
registration
SCR S1, S2, S3,
S4
Register the screen displayed on the FP-e. 9
F181
FP-e screen
display
switching
DSP S Specify the screen to be displayed on the FP-e. 3
Basic function instruction
F182
Time
constant
processing
FILTR S1, S2, S3,
D
Executes the filter processing for the specified
input.
9
F183
Auxiliary
timer (32-bit)
DSTM S, D Turn on the specified output and R900D after
0.01 s. × set value.
7
Data transfer instructions
F190
P190
Three 16-bit
data move
MV3
PMV3
S1, S2, S3,
D
(S1)→(D), (S2)→(D+1), (S3)→(D+2) 10
F191
P191
Three 32-bit
data move
DMV3
PDMV3
S1, S2, S3,
D
(S1+1, S1)→(D+1, D), (S2+1, S2)→(D+3, D+2),
(S3+1, S3)→(D+5, D+4)
16
Logic operation instructions
F215
P215
32-bit data
AND
DAND
PDAND
S1, S2, D (S1+1, S1) AND (S2+1, S2)→(D+1, D) 12
F216
P216
32-bit data
OR
DOR
PDOR
S1, S2, D (S1+1, S1) OR (S2+1, S2)→(D+1, D) 12
F217
P217
32-bit data
XOR
DXOR
PDXOR
S1, S2, D {(S1+1, S1) AND (S2+1, S2)} OR {(S1+1, S1) AND
(S2+1, S2)}→(D+1, D)
12
F218
P218
32-bit data
XNR
DXNR
PDXNR
S1, S2, D {(S1+1, S1) AND (S2+1, S2)} OR {(S1+1, S1) AND
(S2+1, S2)}→(D+1, D)
12
F219
P219
Double word
(32-bit) data
unites
DUNI
PDUNI
S1, S2, S3,
D
{(S1+1, S1) AND (S3+1, S3)} OR {(S2+1, S2) AND
(S3+1, S3)}→(D+1, D)
16
Data conversion instructions
F230
P230
Time data →
second
conversion
TMSEC
PTMSEC
S, D The specified time data ( a date and time) is
changed to the second data.
6
F231
P231
Second
data→ time
conversion
SECTM
PSECTM
S, D The specified second data is changed into time
data (a date and time).
6
