Optional MemoryFP0
2 − 11
2.2 Specifications
Item
Relay output type Transistor output type S−LINK
type
C10RS/
C10RM/
C10CRS/
C10CRM
C14RS/
C14RM/
C14CRS/
C14CRM
C16T/
C16P/
C16CT/
C16CP
C32T/
C32P/
C32CT/
C32CP
T32C SL1
Number of step ladders 128 stages 704 stages
(* Note 1)
128 stages
Number of subroutines 16 subroutines 100 sub-
routines
16 sub-
routines
Number of interrupt programs 7 programs (external 6 points, internal 1 point) 1 program
(internal 1
point)
Self-diagnosis function Such as watchdog timer, program syntax check
Clock/calender function Not available Available
(* Note 3)
Not
available
Special
functions
Pulse catch input
Total 6 points
X0
to
X1:
50
µ
s
Not
available
functions
Interrupt input
X0
to
X1
:
50
µs
X2 to X5: 100µs
available
RS232C port
(* Note 4)
(Only units with an RS232C
port)
Baud rate: 300/600/1200/2400/4800/9600/19200bit/s
Transmission distance: 3m/9.84ft.
Terminal block: 3−pin, made by phoenix Contact Co.
(products number: MKDS1/3−3.5)
Communication method: Half −duplex
Periodical interrupt 0.5ms to 30s interval
Constant scan Available
Password Available
High- speed counter
function
(* Note 5)
Counter mode:
Addition/subtraction (one phase) (* Note 7)
− Input point number:
Four channels maximum
− Maximum counting speed:
10kHz maximum for all 4 channels
− Input contacts used:
X0, X1 50µs, <10kHz>
X3, X4 100µs, <5kHz>
X0: count input (ch 0)
X1: count input (ch 1)
X2: reset input (*Note 8)
X3: count input (ch 2)
X4: count input (ch 3)
X5: reset input (*Note 8)
− Minimum input pulse width:
Not
available
Counter mode:
Two−phase/individual/direction decision (two−phase)
− Input point number:
Two channels maximum
− Maximum counting speed:
2kHz maximum for all 2 channels
− Input contacts used:
X0, X1 50µs, <10kHz>
X3, X4 100µs, <5kHz>
X0: count input (ch 0)
X1: count input (ch 0)
X2: reset input
X3: count input (ch 2)
X4: count input (ch 2)
X5: reset input
− Minimum input pulse width:
Not
available
