Panasonic LP-310 - Power Supply BOX

196
7-2-2 Power Supply BOX
■ LP-310/ LP-310-A
■ LP-310-C
35
140
57.5200
30255
12.5
70
210
(12.5)
315
(4)
95
Key Switch
Main Power
Indicator
Cooling Fan
Interlock Connector
FG
Inlet
Power
Supply
Connector
FUSE
4-M4X0.7 depth 10
4-M4X0.7 depth 10
CO Laser Marker
series
POWER
LP-300
2
(12.5)
140
57.5
255
200
70
12.5
35
30
315
210
(14.5)
95
Key Switch
Main Power
Indicator
Cooling Fan
Interlock
Connector
FG
Inlet
Power
Supply
Connector
FUSE
4-M4X0.7 depth 10
4-M4X0.7 depth 10
