1-5 Connecting with External Device
1-5-1 Operation Sample Using External Control Device
In case of controlling the laser marker with the external control device, the following two connecting methods
are applicable.
1. External Control Using I/O Connector (Remote mode)
2. External Control Using RS-232C (Remote mode)
ABC
PLC
Head
Power Supply BOX
ABC
Personal Computer
Head
Power Supply BOX
Other than external control, the test marking can be performed using the personal computer.
ABC
Head
Power Supply BOX
Personal Computer
<Reference> Test Marking (PC control mode)
