188
5-1
Troubleshooting
If any operation errors occur, check items below first.
When the problems cannot be resolved by following the below measures, please contact us.
Troubles Possible Causes Measures
Ref.
Page
Power supply is not
turned on.
Power cable is not connected.
Connect the power cable.
40
Power cable is not plugged
in outlet
Insert the plug in the socket.
40
The guide laser does
not light.
The shutter lever is not set
to the guide laser side.
Set the shutter lever to the guide laser side.
134
Data cannot be
marked.
The marking start command
is not input.
Input the marking start command.
-
The distance to the work
has not been calibrated.
Calibrate the distance to the work.
54
Laser power and scan
speed are not appropriate
to the marking target
object.
Raise the laser power or lower the scan speed. Or
perform both of them.
126
The trigger signal is kept
ON.
Since the trigger signal sensitive to the edge, input the
edge.
164
The manual shutter is
closed (in remote mode).
Open the manual shutter.
43
The laser radiation stop
input of the I/O connector
is OFF.
Turn ON the laser radiation stop input from the I/O
connector.
13
The interlock of the power
supply BOX is removed.
Attach the optional interlock connector.
12
To Next Page
